STARTING THE MOWER (Fig. E15 – Fig. E16)
WARNING: Avoid sudden starts, stops, and turns, as
well as excessive speed, especially when first learning to
operate the mower. The mower can spin rapidly, which
may cause you to lose control and result in serious injury
and/or damage.
WARNING: Before starting the mower, check and
make sure the blades are disengaged within 5s when
pushing the PTO switch downward. If the blades fail
to stop, do not use the mower and contact your EGO
customer service immediately.
NOTICE: Follow Fig. E17 & Fig. E18 to get the lowest
driving speed and STANDARD driving mode until you are
fully capable of operating the mower in all situations.
The mower will save and present the previous driving
mode, driving speed and calibration of the steering
wheel when restarting it.
Driving-Mode Adjustment (Fig. E17)
◾
CONTROL: Lower acceleration, less sensitive
handling, and mild turning speed to protect the
grass and for new users.
◾
STANDARD: Perfect for everyday use.
◾
SPORT: Higher acceleration, accurate handling,
and sharp turning to maximize mowing efficiency
and for mowing enthusiasts.
NOTE: The driving mode cannot be adjusted during
driving. The function will activate only when the mower
wheels are stopped.
Driving Speed Adjustment (Fig. E18)
Blade Speed Adjustment (Fig. E19)
LED Lights
◾
The headlights, sidelights and rear lights are
controlled by the LED light switch.
◾
The running lights always keep on during driving.
◾
When backing up, if the rear lights are turned off,
they will flash to warn bystanders; if the rear lights
are turned on, they will remain on.
◾
All lights will switch off automatically when the
mower shuts off automatically after a period
without operating.
USB Port
NOTICE: The USB port provides charging power of 5
Voltage DC at up a combined draw of 1.5 Amperes and
is powered only when the mower is startup
STOPPING THE MOWER (Fig. E20)
NOTICE: After more than 60 minutes without operating,
the mower will automatically shut off.
Limp-Home Mode
When battery charge becomes critically low, the mower
will go into Limp-Home mode to preserve enough power
to travel back to the charging area.
◾
The blades switch into low rotation speed, which
could only cut very little amount of grass. Upon
encountering tall and dense grass, the blades will
stop rotating. The audio indicator will sound (beep)
intermittently.
◾
The mower status indicator will flash red every
second, both the low-power indicator and the
battery graphics on the fuel gauge will flash.
The operator should:
◾
Push the PTO switch downward to turn off the
blade motors. The audio indicator will stop
sounding when the blade motors stop.
◾
Stop working and get to the charging area as soon
as possible. The maximum distance the mower
can travel is 1000m.
When the battery is nearly depleted, the icon of each
occupied battery compartment and low-power indicator
will blink every half a second. The mower will stop
working immediately. The operator will have to transport
the mower to the charging area for charging.
NOTICE: If manual pushing is needed, be sure that
the batteries are disconnected from the mower and
the parking-brake pedal is released from the braking
position.
DRIVING THE MOWER (Fig. E21)
DANGER: Stay at least two mowing widths away
from any ditches, drop-offs, or water. Front wheels can
rotate when the mower is stopped, even with the brake
applied, and cause the mower to go over the edge or
into the water and result in death or serious personal
injury.
ZERO TURN RIDE-ON MOWER — ZT4200E-S
EN
25
