Application ex-
ample - TSt ran-
ge
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
Instructions for NOTE! The following guidelines must be followed when installing the external
installing the ex-
version of the interface:
ternal version of -
the interface -
-
-
(3)
(2)
(1)
Cooling unit
Power source
Profibus
Interconnecting hosepack
Wire-feed unit
Welding torch
Robot control
Welding wire drum
Robot
Profibus data cable
The cables must be routed separately from mains leads
The field bus coupler must be installed separately from the mains leads or
components
The field bus coupler may only be installed somewhere that provides protec-
tion from dirt and water
Make sure that the 24 V supply voltage is safely isolated from higher-voltage
circuits.
(5)
(4)
(10)
(6)
(7)
(8)
(9)
