Mechanical installation
microbiological contamination. The screws and tightening torques to be used
are given in the table below:
Version
Standard
M6/M8 (200 kg)
Rustless
M6/M8 (200 kg)
1)
Recommended value for the specified property class. Please comply with the screw
manufacturer's instructions with regard to screw dimensions.
Dimensions in mm
Seal (in
scope of
supply)
Mounting
holes
Mounting plates, connect­
ing parts and screw con­
nections have to be con­
structed by the customer
in accordance with the
EHEDG design guidelines.
Fig. 4.1
Load application and installation
Important
Load must not be applied to the side where the cable connection is located, as
this would cause a force shunt through the cable.
The intermediate plates should be flush against the load cell on all sides (see
connection dimensions in section 6 „Dimensions", page 14).
10
Thread
Max. thread
Platform center
Load application
min. 6 *
* According to the EHEDG design guidelines a minimum
distance of 6 mm is recommended for easy cleanability.
A04856_03_Y00_00 HBM: public
Min. property
reach
12 mm
12 mm
A2-80 or A4-80
min. 6 *
Tightening
class
10.9
14 N⋅m/25 N⋅m
14 N⋅m/25 N⋅m
Product contact area
Mount plug with
tightening torque of
4 Nm
Run the cable
in a straight
line from the
connector
Mounting holes
Seal (in scope of supply)
Mounting base
1)
torque
PW37P
