Danfoss Optyma Slim Pack OP-LSVM Anleitung Seite 76

Instructions
W05 Models: OP-LSVM, MSTM, MSSM and MSIM
V1
PSL
W09 Models: OP-LSVM, MSTM, MSSM and MSIM
V1
PSL
English Legend
B1 Liquid receiver
B2 Filter drier (Flare)
B3 Sight glass (Flare)
D1 FSA connection (Flare)
E1 Liquid service valve
76 | AN37261865152501-010301 - 118A2176C
W1
PSH
PDI
SP
E2
W1
PSH
PDI
SP
E2
E2 Suction service valve
F1 Pressure Relief Valve
FSC Fan Speed Controller
SP 1/4 inch schrader port
PDI Dual pressure switch
V1 Recip compressor
SP
F1
SP
B1
SP
E1
SP
F1
SP
B1
SP
FSC
E1
W1 MHCE with fan
PSL Low Pressure side
PSH High Pressure side
Insulation
© Danfoss | Climate Solutions | 2022.02
D1
B2
B3
D1
D1
B2
B3
D1
