SIX DAYS

APPENDIX: DTC LIST

No. System or component
1 Coolant/Oil Sensor
2
3 Cylinder
4
5 Crankshaft Position Sensor
(CKP)
6
7 Ignition Coil
8
9 Throttle Position Sensor
(TPS)
10
11 Canister Solenoid Valve
12
13 Front Oxygen Sensor
16 -
EN

Error code

Error description

P0118 Coolant/Oil Temperature Sensor Circuit High Voltage or
Open
P0117 Coolant/Oil Temperature Sensor Circuit Low Voltage
P0116 Cylinder temperature constant
P1116 Cylinder temperature too high
P0336 CKP Sensor Noisy Signal
P0335 CKP Sensor No Signal
P2301 Ignition coil "A" short circuit to high voltage (1st cylinder)
P2300 Ignition coil "A" short circuit to low voltage (1st cylinder)/
open circuit
P0123 TPS Circuit High Voltage
P0122 TPS Circuit Low Voltage or Open
P0459 Canister solenoid valve short circuit to high voltage
P0458 Canister solenoid valve short circuit to low voltage/
open circuit
P2A00 Front oxygen sensor signal activate failure
Driver behavior
Stop the engine and check whether the cylinder
temperature sensor is connected effectively. If the error
still persists ask for assistance.
Stop the engine and check whether the cylinder
temperature sensor is connected effectively. Check
if there's enough coolant in engine. If the error still
persists ask for assistance.
Check if the crankshaft position sensor cable (Blue
white/green white cable normally) is connected
effectively. If the error still persists ask for assistance.
Check if the ignition coil circuit is connected effectively.
If the error still persists ask for assistance.
Check if the TPS sensor is connected effectively. If the
error still persists ask for assistance.
Check if the canister solenoid valve circuit is connected
effectively. If the error still persists ask for assistance.
