RIGHT-HAND SIDE VIEW

1) Fuel tank cap
2) Fuel tank
3) Instrument panel
4) Headlight
5) Taillight
3
6) Horn
4
7) Front turning indicators.
8) Rear turning indicators.
7
9) Rear brake disc
10) Rear brake calliper
6
11) Rear brake pedal
12) Rear b rake pump
13) Engine oil flier
14) Air flier
15) Engine oil dipstick
16) Throttle body
17) ABS control unit.
18) Hydraulic fork adjuster
19) Passenger handle
20) Exhaust silencers
