SPARE PARTS LIST FAG-115/500
REF. NR DESCRIPTION
6 PINION GEAR
11 ARMATURE
18 SIDE HANDLE
23 SPINDLE GEAR
31 PROTECTING COVER
33 FLANGE INSIDE
35 FLANGE OUTSIDE
37 STATOR
39 CARBON BRUSH
40 CARBON BRUSH HOLDER
43 SWITCH
45 SLIDE SWITCH KNOB
48 SWITCH DRAW BAR
55 WRENCH
58
FERM NR
406058
ANGLE GRINDER 115 MM
406059
406274
THE NUMBERS IN THE FOLLOWING TEXT COR-
406066 RESPOND WITH THE PICTURES AT PAGE 2
406718
TECHNICAL SPECIFICATIONS
406846
406847
Voltage
Frequency
406060
Power input
406061
No-load speed
406062
Disc diameter
Spindle dimension
406063
Weight
406064
Lpa (sound pressure)
Lwa (acoustic power)
406065
Vibration value
406814
PRODUCT INFORMATION
Fig.A
1. On/off switch
2. Guard
3. Side handle
4. Grinding disc
5. Spindle lock
PACKAGE CONTENTS
The package contains:
1 Angle grinder
1 Side handle
1 Spanner
1 Set carbon brushes
1 Instruction manual

1 Safety instructions

1 Guarantee card
Check the machine, loose parts and accessories for
transport damage.
Ferm Ferm
SAFETY INSTRUCTIONS
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
instructions in this manual.
Denotes risk of electric shock.
Risk of fire.
| 230 V
| 50 Hz
Carefully read this manual before using the machine.
| 500 W
Make sure that you know how the machine functions and
| 11000/min
how to operate it. Maintain the machine in accordance
| 115 mm
with the instructions to make sure it functions properly.
| M14
Keep this manual and the enclosed documentation with
| 1.9 kg
the machine.
| 84.9 dB(A)
| 97.9 dB(A)
When using electric machines always observe the
| 4.6 m/s 2
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions. Keep these
instructions in a safe place!
• Check that the maximum speed indicated on the
grinding disc corresponds to the maximum speed of
the machine. The speed of the machine must not
exceed the value on the grinding disc.
• Make sure that the dimensions of the grinding disc
correspond to the specifications of the machine.
• Make sure that the grinding disc has been mounted
and fastened properly. Do not use reducing rings or
adapters to make the grinding disc fit properly.
• Treat and store grinding discs in conformance with
the supplier's instructions.
• Do not use the machine for grinding workpieces with
a maximum thickness exceeding the maximum grin-
ding depth of the grinding disc.
• Do not use grinding discs for deburring.
• When grinding discs have to be mounted on the
thread of the spindle, make sure that the spindle has
sufficient thread. Make sure that the spindle is suffi-
ciently protected and does not touch the grinding
surface.
• Before use, inspect the grinding disc for any damage.
Do not use grinding discs which are crack-ed, ripped
or otherwise damaged.
• Before use, let the machine run idle for 30 seconds.
Immediately switch off the machine in case of abnor-
mal vibrations or occurrence of another defect.
Carefully inspect the machine and grinding disc
before switching the machine on again.
• Make sure that sparks do not put people into danger
or that they contact highly flammable substances.
• Make sure that the workpiece is sufficiently suppor-
ted or clamped. Keep your hands away from the sur-
face to be cut.
• Always wear safety goggles and hearing protection. If
desired or required also use another kind of protec-
tion like for example an apron or helmet.
3
