C79000-Z8974-C70-02CP 5511 Communications Card under Windows 98, NT 4.0, 2000 Professional

7.3 Making Assignments

Step
1
2
3
4
Note Check the complete settings of your PG/PC interface. In particular,
check the access point and the interface parameter assignment
before continuing with your configuration (see Chapter 8).
The default interface parameter assignments created for a module differ
Properties of the
from each other in terms of the underlying network type and therefore in
Standard
the range of parameters that can be selected.
Parameter
Assignments
Description
Start the "Set PG/PC Interface" configuration program
•
Start the program with the "Start" menu of the
taskbar (Start > Simatic > SIMATIC NET >PB
SOFTNET DP > Set PG/PC Interface, or Start >
Simatic > SIMATIC NET > PB SOFTNET S7 > Set
PG/PC Interface)
or
•
using the Control Panel (Start > Settings >
Control Panel> Set PG/PC Interface)
Select an access point from the list box "Access point of the
application", for example using the mouse.
Reaction: The assigned interface parameter assignment is
displayed in the list box. If no assignment exists, the entry
"<None>" is activated.
Make the assignment between the access point and the device
parameter assignment for example by clicking the required
interface parameter assignment in the "Interface parameter
assignment used" list box with the mouse.
Click the "Properties" button. This opens a dialog in which you
can normally assign parameters to the interface. Depending on
the interface parameter assignment, this button may not be
available. This means that the interface does not require
further parameters.
