6.3 Under Windows 2000 Professional

To install and uninstall the hardware under Windows 2000
Professional, you require administrator rights.
• The parallel operation of SOFTNET cards with other SOFTNET
Important
cards or with a CP 5412(A2) or a CP 5613 is not supported.
• The parallel operation of protocols via SOFTNET cards is not
supported.
• Under Windows 2000, you do not require any further software
Important
(CARDWARE, CARDWIZARD).
• The PCMCIA slot in your computer is of type II or III.
Requirements
• The PCMCIA slot is enabled in the BIOS and is functioning.
• The PCMCIA interface of the computer is installed and operational.
• The CP 5511 must always be connected to the bus adapter.
• The following resources must be available on the computer:
• The CP 5511 requires one of the following interrupts:
IRQ5, IRQ7, IRQ10, IRQ11, IRQ12, IRQ15.
• The CP 5511 requires a free memory area in the first megabyte
of at least 20 Kbytes in the D segment of memory
• The SOFTNET software package is installed.
Step
1 Insert the CP 5511 in a PCMCIA slot. Follow the instructions in the documentation supplied
with the interface.
2 The hardware Wizard will report that new hardware has been found. Click "Next" and complete
with "Finish". You do not need to make any settings, assuming that the SOFTNET package
was already installed.
3 Follow the instructions in Section 7.1 (Completing the Installation in the PG/PC Panel as
for Windows NT 4.0)
Description
