CP 5511 Communications Card under Windows 98, NT 4.0, 2000 Professional C79000-Z8974-C70-02

6.2 Windows NT 4.0

To install and uninstall the hardware under Windows NT, you
must have administrator rights.
• The parallel operation of SOFTNET cards with other SOFTNET
Important
cards or with a CP 5412(A2) or a CP 5613 is not supported.
• The parallel operation of protocols via SOFTNET cards is not
supported.
• The PCMCIA slot in your computer is of type II or III.
Requirements
• The PCMCIA slot is enabled in the BIOS and is functioning.
• The Plug & Play O/S mode must be disabled in the BIOS.
• The PCMCIA interface of the computer is installed and operational.
• If a PCMCIA card is already active on your computer, this must be
removed.
• The CP 5511 must always be connected to the bus adapter.
• There must be no PCMCIA card in a PCMCIA slot since Windows
NT 4.0 does not support the parallel operation of PCMCIA cards.
• The following resources must be available on the computer:
• The CP 5511 requires one of the following interrupts:
IRQ5; IRQ10, IRQ11, IRQ12, IRQ15.
• The CP 5511 requires a free memory area in the first megabyte of
at least 24 Kbytes (20 Kbytes for its DPRAM + 4 Kbytes for
Cardware) in the D segment of memory.
• The SOFTNET software package is installed.
• Before you insert the CP 5511, the SYSTEMSOFT-
CARDWIZARD (preferable) or AWARD CARDWARE must be
installed on the computer. AWARD CARDWARE is on the CD in
the folder SW\CP_5511\AWARD. Follow the steps outlined in
the table. The SYSTEMSOFT CARDWIZARD is on the diskette
supplied with the CP. Installation of the CARDWIZARD is
described in SW\CP_5511\INSYSSFT.PDF.
• If you already have the Card & Socket services of a different vendor
on your computer, this must be completely uninstalled and the
Cardware installed.
18
