Raft
In addition to the three types of support set by software, raft can be added to the
model. Adding raft will increase the adhesion between model and build platform,
thereby minimizing the print failure or warping risk.
Select the shape of the raft as "Skate" and click "Fill" or "Platform" to add the raft and
support.
Note: Before adding the raft, you need to lift the model up by a certain height in the z-
axis direction.
Lift the model up by 5mm (suggested) in the z-axis direction:
•
Set the Z to 5 mm
After lifting the model up, click the " " icon to add support
Step 2: Support adding
You can add the support to the model manually or automatically after setting up the
shape of the support.
Note: The automatic support will override all the previously set supports.
