Technical data

Type mark
Universal motor
Particular current load
Input
Frequency
Movable supply
Security
Revolutions idle of the power spindle
Revolutions idle of the power spindle
Cutting speed at particular load
Mutual inclination of the chain reglet
Weight (without the tool)
Depth of the cut [Guide reglet 18" (45 cm)]

Noise and vibrations

Volumes were measured in accordance with EN 50 144.
For the below stated volumes of noise emissions the addition of K = 4 dB (A) was used as compensa-
tion for possible measuring mistakes.
Level of acoustic performance when idle
Level of acoustic pressure on the measured reference surfaces 100 dB (A)
Weighed value of vibrations affecting hands and arms is
smaller than
Storage
Wrapped machine can be stored in a dry wareh-
ouse without heating, where the temperature
does not go below -5°C. Unwrapped machine can
be stored only in a dry warehouse, where the tem-
perature does not go below +5°C and where sud-
den changes of temperature are avoided.
16
CCP 380
230 V~
13 A
2.800 W
50/60 Hz
H07RN-F
16 A fast safety fuse
5.300 1/min
5.000 1/min
15 m/s
0° - 60°
16,5 kg
at 0° - 380 mm
at 15° - 360 mm
at 30° - 320 mm
at 45° - 250 mm
at 60° - 170 mm
113 dB (A)
2
4,3 m/s
