EloStar Master / EloStar Master smart

2.6.2 Inserting Chip Card into Operating Unit FlatControl

Take optional TwinCard code access / - configuration II.
When Insert card is on display at the operating unit, insert a chip
1.
card TwinCard of the proper type into the card slot. The chip is inside
the upper part of the card. You face the reverse side of the card.
Audibly the card clicks into place.
1) Card slot of FlatControl
2) Chip card TwinCard (code access / configuration II / language)
Wait until Remove card is on display.
2.
3. Remove the chip card from the operating unit.
You have successfully inserted the card and removed it again.

2.6.3 Open a Lock with Code Card (RFID Cards also)

Take the optional chip card TwinCard code access.
Press key Clear and release it immediately, and, if required, press
1.
key < or key > and key Enter in order to select Open.
Code entry | Lock 1 is on display.
With key < or key >, and key Enter select the lock, if required.
2.
Code entry | Standard is on display.
Confirm Standard with key Enter.
3.
Code entry | User: Master is on display.
With keys < or > select the user- / personnel number and Enter, if required.
4.
Code entry |User: no. and
User no. | PIN code are on display.
With key < or key > select Card and Enter.
5.
User: XX | Insert card is on display.
User: XX | Reading data is on display with RFID cards.
6. Insert card TwinCard code access into card slot / Have RFID card read.
See 'Reading the RFID Card at the Operating Unit / Reader' on page 32.
Please wait and, with chip cards, Remove card are on display.
7. Remove the card.
Please wait, afterwards OK and User no. | PIN code may be on
display. In this case, you can additionally enter PIN code, if necessary.
For users, who authenticate via card only, Open| Please wait is on display.
The lock bolt is retracted. Open | Lock open: No. is on display and, with
all locks open, System unlocked. Is displayed, too.
You have successfully opened the lock.
Kurzbedienungsanleitung V.1.01D
Fig. 4: Card and card slot of FlatControl
33
Operation
Quick Reference Guide V.1.01D
TwinCard
