EloStar Master / EloStar Master smart
2.3

Display and Keypad Functions

Both operating units feature the following elements (positions see above in the
descriptions of the operating units) for display and selection of functions.
1) 2-line alphanumeric display with lighting;
after activation the system menu with definable text in the first line and date /
time in the second line is on display:
Menu keys < and > for menu navigation to the previously displayed (<) / to
2)
the following (>) menu item and to select input
Enter-key for affirming / entering the selected menu item / input value
3)
4) Numeric keypad to enter numerals, time designations, and hotkeys
Menu keypad
5)
Clear-key in order to cancel:
6)
press and release
during code input
press and hold 3 sec.
Without operator input, the text will be displayed flashing after about 30 seconds. If
the operator still does not enter anything, the system menu will be displayed. After
that, the display will turn blank.
Depending on the system variant, code is entered via numeric keys or via the menu keys
and Clear- / Enter-keys. A socket for connecting the emergency power is at the bottom
of the operating unit.
You can activate it by pressing any key.
The system is not protected with ex works versions of
system manager – and master code.
Danger of unauthorised opening.
Due to security reasons, change the ex works versions of codes
as soon as possible.
Kurzbedienungsanleitung V.1.01D
EloStar Master
Mo 08.07.19 09:30
-> selects the menu displayed previously
-> undoes entering a number
-> selects the system menu
26
Operation
Caution
Quick Reference Guide V.1.01D
