MT iQ Basic Pro
This product is only suitable for the intended purpose and application in accordance with these
instructions.
This manual provides information that is necessary for proper installation and/or operation of the
product. Poor installation and/or improper operating or maintenance will result in unsatisfactory
performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts provided by the man-
ufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product specifications.
7

Technical description

This device is equipped with a Hall sensor and provide continuous information about the battery
status.
The following values can be shown on the display:
• Remaining battery capacity (%) and (Ah)
• Flowing current (A)
• Battery voltage (V)
• Remaining battery running time (h) (with current consumption)
8

Installing the device

!
WARNING! Electrocution hazard
The installation may only be carried out by a qualified electrician.
No. in
fig. 3,
Description
page 5
1 Consumers
2 Hall sensor
3 MT iQ Basic Pro display
4 On board battery
5 Data cable with power supply wirings and fuse holder
