3G Connection
1. Remove right filter cover.
a. Release the screws on the top.
b. Release the screws on the bottom and pull out the latch.
c. Open and remove the filter cover.
WARNING!
!
Only use a Torx
unit. Use of any other tool may damage screws and panel.
2. Remove the protection cover on the right side.
Installation and Operation Manual
®
Tamper-Resistant T25 screwdriver to secure or remove the screws of
1
3
2
1
2
15
Making the Connection
