PARTS LIST
NO.
NAME
1
Main Body
2
Front Stabilize
3
Rear Stabilizer
4
Saddle Post
5
Handle Post
6
Handle Frame
7
Saddle Adjustment Frame
8
Saddle
9
Monitor
10
Monitor Holder
11
Mobile phone holder
12
Right pedal
13
Left pedal
14
Adjusting knob
ASSEMBLY INSTRUCTIONS
STEP 1
16# 4PCS
17# 4PCS
18# 4PCS
25#
SIZE
QTY. NO.
Assembly
1
Assembly
1
Assembly
1
Assembly
1
Assembly
1
Assembly
1
Assembly
1
Spring loaded
1
Square
1
fit for Φ25tube
1
fit for Φ25tube
1
R
1
L
1
M16
2
Foot adjusters
Moving wheel
18
17
3
16
- 3 -
NAME
15
Adjusting nut
16
Carriage Bolts
17
Flat washer
18
Cover nut
19
Flat washer
20
Button head bolt
21
Spring washer
22
Pulse Wire
23
Signal Wire
24
Self tapping screw
25
Open wrench
27
Inner hexagon spanner
28
six angle bolts
29
Adjusting nut
23
16
SIZE
QTY.
M10
1
M8X50
4
Φ8.5
8
M8
4
Φ10.5
1
M8X16
4
Φ8.5
4
1
1
ST5X25
1
13-15
1
6mm
1
M10X55
1
M8
1
1
18
18
17
16
16
2
