The Front Stabilize (2) is fixed on the Main Body (1) with Carriage Bolts (16), Flat
washers (17) and cover nuts (18), and fixed with open wrench (25).
wheels of the Front Stabilize(2) are forward,as shown.
Similarly, the Rear Stabilizer (3) is fixed on the Main Body (1) with carriage Bolts (16),
flat washers (17) and cover nuts (18), and fixed with open wrench (25).
Attention: The foot adjusters on the rear stabilizer (3) can adjust the machine to the
ground smoothly.The moving wheels on both sides of The Front Stabilize (2) can move the
machine in a short distance.
STEP 2
13
14
Install the right
wrench (25). Note: tighten it clockwise.
Similarly, Install the left pedal (13) with L mark on the Main Body (1) and fixed with an
open wrench (25). Note: tighten counterclockwise.
The adjusting knobs (14) is installed in front and back of the Main Body(1) respectively.
Note that no tightening is needed at this time.
25#
pedal (12) with R mark on The Main Body (1) and fix it with an open
- 4 -
23
12
Note: the move
14
1
