Installation
Disconnect the installation from power before mounting.
Select a plane mounting surface. The bottom of the module
must lie flat on the mounting surface.
1. Screw the lower part onto the mounting surface (mounting holes
mounting screws not supplied).
2. Insert the AS-i standard cable (yellow). Ensure correct positioning of
the cable in the profiled slot.
3. Put the upper part on the lower part and tighten the screws
(screws supplied).
4. Screw the upper part onto the mounting surface (mounting hole
mounting screw not supplied).
If the module is used at the end of the cable line, the ends of the two
flat cables should be secured by means of shrink wraps (order no.
E70113).
Cover the sockets not used with the enclosed protective caps to
guarantee the protection rating IP67.
Maintenance
The operation of the module is maintenance-free.
Always exchange the upper part and lower part at the same time.

Technical data
