Function and features

• maximum number of modules per master: 31 (62 with AS-i master 2.1)
• AS-interface version 2.1
• extended addressing mode possible
• AS-i profile: S-0.A.E
Addressing
At the factory the address is set to 0.
Addressing with the addressing units AC1143 or AC1144
The module can be addressed via the addressing adapters E70123 or
E70211.
Infrared addressing
The AS-i module also offers the option of infrared addressing with the
addressing units AC1143 or AC1144.
The AS-i communication (yellow cable) must be switched off
during the infrared addressing. To do so, disconnect the master.
Supply the slaves with voltage via the AS-i power supply. Addressing is
carried out via the IR addressing cable E70211.
When AS-i power supplies type SL from ifm are used the communica-
tion can be deactivated via a plug on the power supply.
If a slave with the ID code "A" (extended addressing mode pos-
sible) is connected to a master of the first generation (version
2.0), the parameter P3 must be 1 and the output bit D3 = 0*. The
output bit D3 must not be used.
If a slave with the ID code "A" (with extended addressing mode)
is connected to a master of the first generation (version 2.0), an
address between 1A and 31A must be assigned to this slave.
* default setting
