Function and features

• maximum number of modules per master: 31
• AS-interface version 2.1
• AS-i profile: S-3.F.E (AC2458); S-7.F.E (AC2459)

Technical data

You can download
www.ifm-electronic.com if required.
Addressing
Assign a free address between 1 and 31. At the factory the address is
set to 0.
Addressing with the addressing units AC1143 or AC1144
The module can be addressed via the addressing adapters E70123 or
E70211.
Infrared addressing
The AS-i module also offers the option of infrared addressing with the
addressing units AC1143 or AC1144.
The AS-i communication (yellow cable) must be switched off
during the infrared addressing. To do so, disconnect the master.
Supply the slaves with voltage via the AS-i power supply. Addressing is
carried out via the IR addressing cable E70211.
When AS-i power supplies type SL from ifm are used the communica-
tion can be deactivated via a plug on the power supply.
the data sheet from the Internet
