Addressing
Fix the module onto the addressing unit. Assign a free address
between 1 and 31; the factory preset is 0.
Addressing with the addressing unit AC1143 or AC1144
The mounted and wired module can be addressed with the addressing
cable (E70213) via the addressing socket.
Only address via the addressing socket when disconnected.
Operation
Check the safe functioning of the unit. Display by LEDs:
• LED green: voltage supply via the AS-i network o.k. or external
power supply o.k.
• LED yellow: input/output switched
• LED red is lit: AS-i communication error, e. g. slave address 0
• LED red flashing: peripheral fault, e.g. no auxiliary voltage

Technical data

You can download the data sheet from the Internet if required
(www.ifm-electronic.com).
