Maintenance Schedule
First 5 Hours
• Change oil
Every 8 Hours or Daily
• Check engine oil level
• Clean area around muffler and controls
• Clean air intake grille
Every 25 Hours or Annually
• Clean air filter
1
• Clean pre-cleaner 1
Every 50 Hours or Annually
• Change engine oil
• Check muffler and spark arrester
Every 100 Hours
• Change gear reduction oil (if equipped)
Annually
• Replace spark plug
• Replace fuel filter
• Replace pre-cleaner
• Clean air cooling system
1
1
In dusty conditions or when airborne debris is present, clean more often.
Carburetor and Engine Speed
Never make adjustments to the carburetor or engine speed. The carburetor was set at
the factory to operate efficiently under most conditions. Do not tamper with the governor
spring, linkages, or other parts to change the engine speed. If any adjustments are
required contact a Briggs & Stratton Authorized Service Dealer for service.
NOTICE The equipment manufacturer specifies the maximum speed for the engine
as installed on the equipment. Do not exceed this speed. If you are not sure what the
equipment maximum speed is, or what the engine speed is set to from the factory,
contact a Briggs & Stratton Authorized Service Dealer for assistance. For safe and
proper operation of the equipment, the engine speed should be adjusted only by a
qualified service technician.
Service Spark Plug
See Figure: 6
Check the gap (A, Figure 6) with a wire gauge (B). If necessary, reset the gap. Install
and tighten the spark plug to the recommended torque. For gap setting or torque, see
the Specifications section.
Note: In some areas, local law requires using a resistor spark plug to suppress ignition
signals. If this engine was originally equipped with a resistor spark plug, use the same
type for replacement.
Service Exhaust System
WARNING
Running engines produce heat. Engine parts, especially muffler, become
extremely hot.
Severe thermal burns can occur on contact.
Combustible debris, such as leaves, grass, brush, etc. can catch fire.
• Allow muffler, engine cylinder and fins to cool before touching.
• Remove accumulated debris from muffler area and cylinder area.
• It is a violation of California Public Resource Code, Section 4442, to use or
operate the engine on any forest-covered, brush-covered, or grass-covered land
unless the exhaust system is equipped with a spark arrester, as defined in Section
4442, maintained in effective working order. Other states or federal jurisdictions
may have similar laws. Contact the original equipment manufacturer, retailer, or
dealer to obtain a spark arrester designed for the exhaust system installed on this
engine.
Remove accumulated debris from muffler and cylinder area. Inspect the muffler for
cracks, corrosion, or other damage. Remove the deflector or the spark arrester, if
8
equipped, and inspect for damage or carbon blockage. If damage is found, install
replacement parts before operating.
WARNING
Replacement parts must be of the same design and installed in the same position
as the original parts. Other parts may not perform as well, may damage the unit, and
may result in injury.
Change Engine Oil
See Figure: 7, 8
Used oil is a hazardous waste product and must be disposed of properly. Do not discard
with household waste. Check with your local authorities, service center, or dealer for
safe disposal/recycling facilities.
Remove Oil
1. With engine off but still warm, disconnect the spark plug wire (D, Figure 7) and
keep it away from the spark plug (E).
2. Remove the dipstick (A, Figure 8).
3. Remove the oil drain plug (F, Figure 8). Drain the oil into an approved container.
Note: Various oil drain plugs (G, Figure 8) are installed in the engine.
4. After the oil has drained, install and tighten the oil drain plug (F, Figure 8).
Add Oil
• Make sure the engine is level.
• Clean the oil fill area of any debris.
• See the Specifications section for oil capacity.
1. Remove the dipstick (A, Figure 8) and wipe with a clean cloth.
2. Slowly pour oil into the engine oil fill (C, Figure 8). Fill to point of overflowing.
3. Install the dipstick (A, Figure 8). Do not turn or tighten.
4. Remove the dipstick and check the oil level. Correct oil level is at the top of the full
indicator (B, Figure 8) on the dipstick.
5. Reinstall and tighten the dipstick (A, Figure 8).
6. Connect the spark plug wire (D, Figure 7) to the spark plug (E).
Change Gear Reduction Oil
See Figure: 9, 10
6:1 Gear Reduction (Figure 9)
If your engine is equipped with a 6:1 gear reduction unit, service as follows:
1. Remove the oil fill plug (A, Figure 9) and the oil level plug (B).
2. Remove the oil drain plug (C, Figure 9) and drain the oil into an appropriate
receptacle.
3. Reinstall and tighten the oil drain plug (C, Figure 9).
4. To refill, slowly pour gear lube (see Specifications section) into the oil fill hole
(D, Figure 9). Continue to pour until the oil runs out of the oil level hole (E).
5. Reinstall and tighten the oil level plug (B, Figure 9).
6. Reinstall and tighten the oil fill plug (A, Figure 9).
Note: The oil fill plug (A, Figure 9) has a vent hole (F) and must be installed on the top of
the gear case cover as shown.
2:1 Gear Reduction (Figure 10)
The 2:1 gear reduction unit (G, Figure 10) does not require an oil change.
Service Air Filter
See Figure: 11, 12
WARNING
Fuel and its vapors are extremely flammable and explosive.
Fire or explosion can cause severe burns or death.
• Never start and run the engine with the air cleaner assembly (if equipped) or the
air filter (if equipped) removed.
