4.19
Installation of the safety guard over the top roller and/or drive
GB
1.
Place the holder profile on the consoles
and fix them on the mounting surface
above the console.
See fig. 4.20
2.
Slide the sleeve over the box with the
mounting plate and attach it to the conso-
les using 2 X 2 M8 bolts (finger tight).
3.
Place the safety guard onto the holder pro-
file and then decide whether the box is in
the right place (if necessary, move the box
until the safety guard is adjacent).
4.20
end cap
sleeve with mounting plate
With this the mechanical part of the installation is finished. For the installation of the
operating system please see the relevant manual. The operating system can be supplied
with a magnetic switch or with a frequency controller. Please make sure you are using the
correct manual.
14
14
4.
Tighten the M8 bolts.
5.
Place the cover over the drive.
6.
Slide the end cap to the driven side in
the safety guard and secure it with the
supplied self-tapping screws.
7.
Attach the cover to the sleeve using
the supplied plastic nails. Drill holes
through the cover and in the box, and put
the nails there.
70
holder profile
sleeve
nails
nails
4.21
Notes
GB
15
15
