17 Technical Information
Connection J1 Remote I/O Interconnections
The vent could damage the pump. Please, use the "Auto Pump Speed" mode or
CAUTION!
refer to Agilent personnel.
On Command Mode – with Purge/Vent Device
Accessory Only
If WIN 125 = 1 the vent valves can be operated manually via serial
communication (or by front panel interface) with the followings
limitations.
Setting WIN 122 = 1 the Vent Valve opens only if the pump is in STOP
status: if the pump is in STARTING, NORMAL or AUTOTUNING
status the valve stays close; if the pump is in BRAKING status, the
Vent Valve performs a Controlled Venting.
Setting WIN 122 = 0 the Vent Valve is closed independently from the
pump status.
Autotime Mode – with Purge/Vent Device
Accessory Only
If WIN 125 = 0 the Vent and Purge Valves are opened as a function of time
(see the figure below for details). The timings are configurable through WIN
126 (Vent Valve Opening Delay) and WIN 147 (Vent Valve Opening Time).
228/288 Turbo-V 2300 TwisTorr Rack Controller User Manual / 87-901-044-01
