14 Do not keep batteries near fire, ovens or other
sources of heat. Do not use batteries in direct sun-
light or store them in vehicles in hot weather.
15 Keep unused batteries in the original packaging and
keep them away from metal objects. Do not mix
unpacked batteries or toss them together! This can
lead to a short-circuit of the battery and thus dam-
age, burns or even the risk of fire.
16 Remove batteries from the equipment when it will
not be used for an extended period of time, unless
it is for emergencies!
17 NEVER handle batteries that have leaked without
appropriate protection. If the leaked fluid comes into
contact with your skin, the skin in this area should be
rinsed off under running water immediately. Always
prevent the fluid from coming into contact with the
eyes and mouth. In the event of contact, please seek
immediate medical attention.
18 Clean the battery contacts and corresponding con-
tacts in the device prior to inserting the batteries:

6. Technical data

AC motor
Power
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Swivel range
Mitre cut
Saw width at 90°
Saw width at 45°
Saw width at 2 x 45°
(double mitre cut)
Protection class
Weight
Laser class
Wavelength of laser
Laser output
Laser module power
supply
* S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed
by a period at no load. Running time 10 minutes;
duty cycle is 25% of the running time.
The work piece must have a minimum height of 3mm
and a minimum width of 10 mm.
Make sure that the workpiece is always secured with
the clamping device.
24 GB/IE
220 - 240 V ~ 50Hz
1500 Watt
S6 25%*
5000 min
-1
ø 210 x ø 30 x 2,6 mm
24
-45° / 0°/ +45°
0° bis 45° nach links
340 x 58 mm
240 x 58 mm
240 x 32 mm
II
approx. 17 kg
2
650 nm
≤ 1 mW
2 x 1,5 V Micro (AAA)
Noise
Total vibration values determined in accordance with
EN 61029.
sound pressure level L
pA
uncertainty K
pA
sound power level L
WA
uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing.

Residual risks

The machine has been built according to the state of
the art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Health hazard due to electrical power, with the use of
improper electrical connection cables.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the „safety instruc-
tions" and the „Proper use" are observed along with
the whole of the operating instructions.
• Do not load the machine unnecessarily: excessive
pressure when sawing will quickly damage the saw
blade, which results in reduced output of the machine
in the processing and in cut precision.
• When cutting plastic material, please always use
clamps: the parts which should be cut must always
be fixed between the clamps.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual. In do-
ing so, your mitre saw provides optimal performance.
• Hands may never enter the processing zone when
the machine is in operation. Release the handle but-
ton and switch off the machine prior to any operations.

7. Before starting the equipment

• The equipment must be set up where it can stand se-
curely, i.e. it should be bolted to a workbench, a uni-
versal base frame or similar.
• All covers and safety devices have to be properly fit-
ted before the equipment is switched on.
• It must be possible for the blade to run freely.
• When working with wood that has been processed
before, watch out for foreign bodies such as nails or
screws, etc.
• Before you press the ON/OFF switch check that the
saw blade is fitted correctly. Moving parts must run
smoothly.
• Before you connect the equipment to the power sup-
ply make sure the data on the rating plate are dentical
to the mains data.
99.6 dB(A)
3 dB
112.6 dB(A)
3 dB
