Comet CPS 55 ADVANCE BYT Bedienungsanleitung Seite 31

Photo 6
A Brush motor operating push button
B Suction motor operating push button
G Detergent outflow adjusting push
button
F Forward/reverse traction push button
selector
C+ Traction speed increase push button
C - Traction speed reduce push button
H Operating informations display
Photo 7
Percentage of dilution of the detergent
1 Dilution with half outflow of clean water
2 Dilution with complete outflow of
clean water
4.2. DIMENSIONS
All dimensions are in millimetres.
1261
Model 500 mm cleaning width
Photo 8
A
B
G
Photo 6
1/2
1
6,0
4,5
3,4
2,3
1,3
%
Photo 7
Model 550 mm cleaning width
Model 660 mm cleaning width
31
H
H O
1/1
3,0
2,3
1,7
1,2
0,6
%
CHEM.
1286
1212
F
C
+
C
-
2
