Automatic Integrity Test (Pressure Delay) - Sartorius Sartocon Slice Disposable Installation Und Betriebsanleitung

Checking the Functionality of the Filter Cassettes
3.2

Automatic Integrity Test (Pressure Delay)

Proceed as follows:
(Pressure Decay)
1. Connect the integrity tester [such as or Sartocheck
Sartocheck 4 Plus (26288)] to the power supply and pressure source.
®
2. Close the retentate outlet (V₂) and open the permeate outlets (V₃, V₄).
Open V₅ and close V₁.
3. Enter the required test parameter according to the Sartocheck
instruction manual and cassette data.
4. Use the following parameter:
stab. time: 4 min .
test time: 2 min .
5. Enter the maximum allowable diffusion value (see "6 Technical Data").
6. Start the Integrity Test.
Sartocheck
Retentate outlet
closed
Fig. 5: System setup for automatic integrity testing
V₁–V₅: valves; P: pump; PI: pressure gauges; B: buffer volume
If the retentate volume exceeds 9 l for a Sartocheck
Sartocheck 4 Plus, please contact your Sartorius Stedim application
®
specialist.
16 Installation and Operating Instructions Sartocon
Buffer volume
®
B
V2
P V1
Feed inlet
closed
4 (16288) or
®
V5
Pl
Cassette
Pl
V4
PI
V3
Permeate
4 or 14 l for a
®
Slice Disposable
®
®
