System Commands; Dimensions - bürkert LEVEL SWITCH 8110 Bedienungsanleitung

Designation
Peak value - Min.
temperature
Peak value - Max.
temperature
Consider the respective gradient when calculating the correct values.

System commands

Designation
Restore factory settings
9.3

Dimensions

LEVEL SWITCH 8110, standard version
ø 31,7 mm
(1.25")
1
Fig. 12: LEVEL SWITCH 8110, standard version - threaded fittings
1 Thread G½ (DIN ISO 228/1), ½ NPT, M12 x 1 plug
2 Thread G¾ (DIN ISO 228/1), ¾ NPT, M12 x 1 plug
3 Thread G1 (DIN ISO 228/1), 1 NPT, M12 x 1 plug
4 Switching point
Keep in mind that the total length is extended by the plug connection.
1)
LEVEL SWITCH 8110 • IO-Link
ISDU ISDU Size
(dez) (hex) (Byte)
154 0x9A
155 0x9B
ISDU (dez)
130
M12 x 1
SW 32 mm
(1.26")
G 1 / , 1 / NPT,
2 2
R 1 /
2
ø 17 mm
(0.67")
Data Access
type
2 Int RO
2 Int RO
ISDU (hex) Access
82 W
G 3 / , 3 / NPT,
4 4
R 3 /
4
ø 21,3 mm
(0.84")
2
1)
9 Supplement
Default-Value Gradient
- 0.1
- 0.1
G1, 1 NPT,
R1
ø 21,3 mm
(0.84")
3
4
25
