5 Connecting to power supply
14
Max.
2
3
-
L
Fig. 8: Wiring plan (housing), terminal assignment IO-link output with M12 x 1
plug connection
1 L+ Voltage supply (brown)
2 Max. level detection (white)
3 L- Voltage supply (blue)
4 Min. level detection/IO-Link communication (black)
R Load resistance (contactor, relay, etc.)
L
Min.
1
4
+
C/Q1 L Q2
LEVEL SWITCH 8110 • IO-Link
2 1
3 4
R
L
- +
L L
