3. Powering on the CMTS 2-00

This section includes checking before switching on and checking the display after switching on.
Make sure that the CMTS 2-00 is switched off before checking the installation to avoid injury and damage.

3.1. Checks before switching-on

After the installation is complete, check the following items:
·
The CMTS 2-00 is correctly connected to the equipotential bonding.
·
The mains cable(s) is/are connected to the mains socket.
·
The diameters of the mains cable and grounding cable are in accordance with the technical design
document and requirements.
·
The mains cable and the grounding cable are made entirely of copper core materials and are intact and
without damage to the sheath.
· The mains cable and the earthing cable are correctly laid, and there is an appropriate cable reserve.
·
The mains cable and the grounding cable and signal cables are laid separately.

3.2. Checks after switching-on

LED Description
PWR A On: The output of the power module A is normal.
Off: The output of power module A is not correct.
PWR B On: The output of the power module B is normal.
(optional)
Off: The output of power module B is not correct.
RUN Green blinking: CMTS 2-00 initialization is complete.
Off: CMTS 2-00 initialization is not complete.
PWR On: The power supply is normal.
Off: The power supply is of or voltage to low.
