Carel compactSteam Benutzerhandbuch Seite 22

FRE
Modèles CH004N0003
Légende
EVF Vanne de remplissage
DP Vanne de vidange
DT Soupape de revenu
HL Capteur de haut niveau
EMBEDDED
BLOWER
STEAM
BOILER UNIT
DP
0 230
SECONDARY
TRANSFORMER
PRIMARY
230 0 115
"compactsteam" +0300092FD - rel. 1.3 - 16.08.2021
HL
DT EVF
WATER OUTLET
WATER
INLET
VOLTAGE SWITCH
1b
1
1a
2 5
ON/OFF SWITCH
1 4
Fig. 3.ae
HL
N
EVF
DP
N
F
INT
FAN
E1
E2
N F
N
F
L1 L2
EXTERNAL FUSED DISCONNECT
TO BE INSTALLED (NOT SUPPLIED)
RESPECT LOCAL CODES
POWER SUPPLY
(100Vac 1-PHASE 50-60 HZ
OR
230Vac 1-PHASE 50-60 HZ)
22
PROGRAMMING PORT
AIR PRESSURE SWITCH
HUMIDISTAT
ALARM
EXTERNAL DUCT FAN
24Vac FOR
EXTERNAL
HUMIDISTATS
CONNECTED
TO GROUND
