Bedienungsanleitung EE300Ex Feuchte / Temperatur Sensor
Application temperature of the probes:
Specification of the temperature class "TKG" for use in gas explosion hazardous areas and the
temperature "TKD" for use in dust explosion hazardous areas depending on the ambient tempera-
ture "T " with respect to the temperature and humidity probe.
amb
TKG TKD Humidity and Temperature
Probe
T6 80 °C
-40 °C ≤ T
T5 95 °C -40 °C ≤ T
T4 130 °C -40 °C ≤ T
T3 195 °C -40 °C ≤ T
T2 200 °C -40 °C ≤ T
T1 200 °C -40 °C ≤ T
Models:
Model
EE300Ex-M1: Measurement of relative humidity (RH) and temperature (T)
EE300Ex-M3: Temperature measurement only
T1
Wall mount with fixed probe
D0: without display
D1: with display
Type of connection (measuring channels):
E13: Conduit Adapter (metal)
E32: M12-Plug (plastic)
E2, E15, E17, E18, E19, E20, E21, E22:
cable gland (metal)
K0
Lx: probe length [mm]: 50 mm / 70 mm
Test report: 713215990
EU-Type Examination Certificate without signature shall not be valid. The certificates may be circulated only without altera-
tion. Extracts or alterations are subject to approval by TÜV SÜD Product Service GmbH.
The document is internally administrated under the following number: EX5A 038892 0010 Rev.01
TÜV SÜD Product Service GmbH • Zertifizierstelle • Ridlerstraße 65 • 80339 München • Deutschland
TKD
80 °C
≤ +60 °C
amb
≤ +75 °C 95 °C
amb
≤ +110 °C 130 °C
amb
≤ +175 °C 195 °C
amb
≤ +180 °C 220 °C
amb
≤ +180 °C 220 °C
amb
T7, T9, T10, T15, T22, T24
Remote probe with fixed cable
The code number after the T stands for the
probe type.
D0: without display
D1: with display
Type of connection (measuring channels):
E13: Conduit Adapter (metal)
E32: M12-Plug (plastic)
E2, E15, E17, E18, E19, E20, E21, E22:
cable gland (metal)
Kx: cable length [m]: 0,2 m to 10 m
Lx: probe length [mm]: 65 mm to 1000 mm
In case of dispute, the German text shall prevail.
Temperature Probe
-70 °C ≤ T ≤ +60 °C
amb
-70 °C ≤ T ≤ +75 °C
amb
-70 °C ≤ T ≤ +110 °C
amb
-70 °C ≤ T ≤ +175 °C
amb
-70 °C ≤ T ≤ +200 °C
amb
-70 °C ≤ T ≤ +200 °C
amb
