E+E Elektronik EE210 Kurzanleitung

QUICK GUIDE - EE210 MODBUS SETUP
(Full User's Guide at www.epluse.com/EE210)
Address Switch
0 0 0 0 0 0 0 0
Address Switch
1 1 0 1 0 0 0 0
MODBUS MAP
The measured values are saved as a 32Bit float value from 0x19 to 0x1F and from 0x23 to 0x29. Additionally the measured values
are available as 16Bit signed integer from 0x12C to 0x12F and from 0x131 to 0x134.
The factory setting for the Slave-ID (Modbus address) is 242 as an integer 16Bit value. This ID can be changed by the user in the
register 60001 (0x00), permitted values are 1 - 247 permitted.
The serial number as ASCII-code is located at register address 30001-30008 (16Bit per address).
The Firmware version is located at register address 30009 (Bit 15...8 = major release; Bit 7...0 = minor release).
The choice of measurement units (metric or not metric) must be done in the ordering guide, see EE210 data sheet.
Switching from metric to non metric or vice versa by using the EE-PCS is not possible.
FLOAT (read register):
Register Communication
address address
30026 0x19
30028 0x1B
30030 0x1D
30032 0x1F
30036 0x23
30038 0x25
30040 0x27
30042 0x29
INTEGER (read register):*
Register Communication
address address
30301 0x12C
30302 0x12D
30303 0x12E
30304 0x12F
30306 0x131
30307 0x132
30308 0x133
30309 0x134
* Values are stored with a scaling of 1:100 (e.g.: 2550 is equivalent to 25.5°C)
Protocol setting:
Address, baudrate, parity and stop bits can be set via:
1. Configurator software (available on www.epluse.com/EE210)
2. Modbus protocol (please see Application Note Modbus (available on www.epluse.com/EE210)
InfOrMaTIOnEn
E+E Elektronik Ges.m.b.H.
Langwiesen 7 • A-4209 Engerwitzdorf
Tel: +43 7235 605-0 • Fax: +43 7235 605-8
info@epluse.com • www.epluse.com
LG Linz Fn 165761 t • UID-Nr. ATU44043101
Place of Jurisdiction: A-4020 Linz • DVR0962759
Downloaded from www.Manualslib.com
Slave address setting via EE-PCS Product Configuration Software:
All switches at position 0 → address has to be set via configuration software (factory setting 242).
Example: Slave address is set via configuration software.
Slave address setting via Dip-Switch:
Setting the Dip-Switch to any other address than 0 overwrites the slave address set via configuration software.
Example: Slave address set to 11 (=00001011 binary).
Parameter
name
temperature
relative humidity
water vapour partial pressure
dew point temperature
absolute humidity
mixing ratio
specific enthalpy
frost point temperature
Parameter
name
temperature
relative humidity
water vapour partial pressure
dew point temperature
absolute humidity
mixing ratio
specific enthalpy
frost point temperature
manuals search engine
INFO (read register):
Register Communication
address address
30001
[°C], [°F]
[%] 30009
[mbar], [psi]
INTEGER (write register):*
[°C], [°F]
Register Communication
[g/m³], [g/ft³]
address address
[g/kg], [gr/lb]
60001
[kJ/kg], [BTU/lb]
60002
[°C], [°F]
*For Modbus protocol setting please see Application Note Modbus
(www.epluse.com/EE210)
[°C], [°F]
[%]
[mbar], [psi]
[°C], [°F]
[g/m³], [g/ft³]
[g/kg], [gr/lb]
[kJ/kg], [BTU/lb]
[°C], [°F]
+43 7235 605 0 / info@epluse.com
BA_EE210_QGMS // v1.0 // Modification rights reserved // 302728
Parameter
name
0x00
Serial number
0x08 Firmware version
Parameter
name
0x00 Slave-ID (modbus addresse)
0x01
Modbus protocol settings*
