Preparation Before Use

EN
1. Remove the protective matter
2. Install the side brush
Click
Note: Install the side brush until it clicks into place.
8
3. Fasten the damp-proof pad
Select a clean location to place the charging dock. Tear off the
adhesive tape at the bottom of the damp-proof pad, and stick the
pad on the ground as shown in the figure.
Note:
· It is recommended that the damp-proof pad be fastened on the wooden floor.
· If you need to remove the damp-proof pad, please remove it slowly to avoid
adhesive residue.
Preparation Before Use
4. Connect to a power outlet
Place the charging dock on the level ground against the wall and
connect it to a power outlet.
＞ 0.5 m
＞ 0.5 m
＞ 1.5 m
Note:
· Keep the immediate area 1.5m in front of the charger and 0.5m to both sides
of the charging dock clear of objects.
· To ensure you can connect to the robot with your phone well, make sure the
robot and charging dock are within WiFi range.
· Do not place the charging dock in an area with direct sunlight or where other
objects might block the signal, as this may hinder the robot from returning to
the charging dock.
5. Start recharging
Place the robot onto the charging dock to recharge. The robot will
turn on automatically and begin recharging.
Battery Level Indicator
· White: Battery level is more than 15%
· Orange: Battery level is less than 15%
Note: It is recommended to fully charge your robot before first-time use.
