ASSEMBLY
Step 4
128 128
Loosen the preassembled screws and washer from the middle post (4-1).
Connect the cables from the main unit with the cables from the middle post (4-2).
Mount the middle post with the main unit with the screws and washer (4-3).
7 7
13 13
4- 1 4- 1
25 25
4- 2 4- 2 4- 3 4- 3
