General Technical specifications
Reference standard
Power supply voltage
Frequencies
Absorbed power (S)
Sensitivity settings (I∆ n)
Tripping time settings
Output contact range (tn)
Operating temperature
(
)
*
"FAST" times temperature selection corresponds to tripping time of 50 ms
EN62020
110÷400 VAC, 48÷110 VDC ± 10% 15%
50÷60 Hz
0,8 W a 110 VAC
1,8 W a 230 VAC
6,8 W a 400 VAC
0,2 W a 48 VDC
1 W a 110 VDC
0,03 - 0,1 - 0,3 - 0,5 - 1 - 2 A
(
)
FAST
*
- 0,3 - 0,5 - 1 - 2 - 5 s
10 A - 250 V
-5÷40 °C
11
