TAB.
POS.
Part Nr
2
1
2109901 SOLLEVAMENTO BRACCIO CONTENITORE
2
2
2107743 CONTENITORE
2
3
3007297 CERNIERA " STANLEY"
2
4
4200189 PROFILO MUSSE 20X4X4000
2
5
3009967 COPERCHIO CONTENITORE
2
6
3010230 CHIUSURA PER FANALE ANTERIORE
2
7
4200679 PIASTRINA DI ATTACCO E OCCHIELLO
2
8
4200678 TIRANTE AGGANCIO COFANO
2
9
4200814 PIEDINO ANTIVIBRANTE
2
10
3001343 SUPPORTO PERNO RIBALTAMENTO
2
11
4200420 BOCCOLA GB3030
2
12
2107787 RISCONTRO ASTA DI SICUREZZA
2
13
4200622 BUSSOLA K4 20X23X20
2
14
3004264 RONDELLA 20,5X30X1,5
2
15
3002271 RONDELLA DI SPESSORAMENTO D.30X10.5X5
2
16
4200581 TAPPO
2
17
3007789 SCIVOLO PER AGGANCIO ASTA
2
18
3007114 MOLLA FERMO ASTA
2
19
4201713 MOLLA A TAZZA D.40X20.4X1 DIN 2093
2
20
2107783 ASTA DI SICURAZZA
2
21
2109880 SUPPORTO PEDIPOLATORE
2
22
4200627 INTERRUTTORE LUCI ARRESTO
2
23
4201699 CHIODINO ZINCATO CON RONDELLA
2
24
2109963 PARAURTI ANTERIORE
2
25
3001748 FERMO PER COFANO
2
26
3010250 GOMMA SEPARAZIONE ARIA
2
27
2109973 PROTEZIONE PARAURTI ANTERIORE
2
28
4201358 CERNIERA 30X55
2
29
3010078 PIATTO FISSAGGIO COFANO ANTERIORE
2
30
3010200 RISCONTRO
2
31
3010201 PERNO RISCONTRO
2
32
3000294 CAVO IN ACCIAIO PER COFANO
2
33
2110223 COFANO ANTERIORE
2
34
4201289 TAMPONE IN GOMMA
2
35
3010224 PIATTO APPOGGIO TAMPONE
2
36
3000098 RONDELLA
2
37
4209980 CATADIOTTRO ANTERIORE D.86
2
38
3010028 PLASTICA PARAURTO ANTERIORE
2
39
4300036 RONDELLA D.8,4 X 17 UNI 6592 ZINC.
2
40
4300108 VITE TE M8 X 30 UNI 5739-8.8 ZINC.
2
41
4300053 DADO M8 AUTOFRENANTE UNI 7473
2
42
4300158 VITE TBEI M4 X 12 UNI7380
2
43
4300049 RONDELLA D.4,3X 9 UNI 6592 ZINC.
2
44
4300056 DADO M4 AUTOFRENANTE UNI 7473
2
45
4300059 VITE TSPTCI M4X10 UNI 7688-4 ZINC.
2
46
4210238 GRIGLIA LATERALE
2
47
4300222 VITE TBEI M8 X 20 ISO 7380 ZINC
2
48
4300048 RONDELLA D.6,4 X 12 UNI 6592 ZINC.
2
49
4300047 VITE TE M6 X 16 UNI 5739-8.8 ZINC.
2
50
4300079 DADO MEDIO M6 UNI 5588-6S ZINC.
2
51
4300087 VITE TE M6 X 25 UNI 5739-8.8ZINC.
2
52
4300039 RONDELLA D.17X 30 UNI 6592 ZINC
2
53
4300038 DADO AUTOFRENANTE M16 UNI 7473
2
54
4300051 DADO M6 AUTOFRENANTE UNI 7473
2
55
4300034 RONDELLA D.10,5X 21 UNI 6592 ZINC.
2
56
4300204 VITE TE M10 X 30 UNI 5739-8.8 ZINC.
2
57
4300025 VITE TE M10 X 25 UNI 5739-8.8 ZINC.
2
58
4300162 VITE TE M16 X 50 UNI 5739- 8G ZINC.
2
59
4300237 VITE TBEI M 10 X 20 UNI7380
2
60
4300247 VITE TBEI M6 X 15 UNI 7380 ZINC.
2
61
4300155 DADO IN GABBIA M6
2
62
4300437 Vite TSPEI M6x20 UNI 5933-8.8 Zincata
2
63
4300178 DADO ESAG.MEDIO M10 UNI 5588 / ZINC.
2
64
4300232 VITE TBEI M 8 X 30 UNI7380
2
65
4300224 RONDELLA D. 6,4 X 18 UNI 6593 ZINC.
2
66
4300173 VITE TBEI 6 X 20 ISO 7380
2
67
4300029 DADO ESAG.MEDIO M8 UNI 5588 / ZINC.
2
68
4300042 RONDELLA D.5,3X 10 UNI 6592 ZINC
2
69
3010429 DISTANZIALE
2
70
4300282 Vite TE M5x10 UNI 5739-8.8 ZINC.
2
71
4300351 VITE TSPEI M6 x 25 UNI 5933 ZINC.
2
72
4210237 GRIGLIA CENTRALE
2
73
4210313 MANIGLIA
2
74
4200227 CLACSON 12V
2
75
2103588 PEDIPOLATORE
2
76
4210314 CHIUSURA
2
77
4300125 RONDELLA D.6,4 X 24 UNI 6593 ZINC.
2
78
4300106 VITE TE M6 X 40 UNI 5739-8.8 ZINC.
2
79
3010355 TAPPO PER MANIGLIA
2
80
4300050 VITE TE M6 X 20 UNI 5739-8.8 ZINC.
2
81
4300378 PIASTRINA PER VITE AUTOFILETTANTE 4,8
2
82
4300379 VITE AUTOFILETTENTE 4,8x19 NERA
2
83
3006921 PIASTRINA DI ATTACCO
Part Nr
refers always to one single parts
Contenitore e paraurti 2209875
DENOMINAZIONE
Qty
1
Hopper lifting arm
1
Hopper
2
Hinge "Stanley"
1
Gasket 20x4x4000
1
Hopper cover
2
Front light closing
2
Plate of attack and eyelet
2
Tierod hooking bonnet
2
Silent block
2
Pin tip support
2
Bush GB 3030
1
Safety rod feedback
1
Socket K4 20x23x20
4
Flat washer 20,5X30X1,5
2
Washer D 30x10x5
2
Cap
1
Safety rod housing
1
Safety rod spring
4
Spring washer D.40x20.4x1 DIN 2093
1
Safety rod
1
Support control pedal
1
Stop Light switch
2
Brad galvanized with washer
1
Front bumper
3
Stop for bonnet
1
Rubber air separation
1
Front bumper protection
2
Hinge 30x55
2
Fixing plate for bonnet
1
Abutment
1
Pivot abutment
2
Steel cable for bonnet
1
Front bonnet
2
Rubber buffer
2
Plate buffer support
4
Washer
2
Front reflector
1
Plastic front bumper
58
Flat washer 8,4 x 17 ISO 7089 Galvanized
22
Hexagon screw M8x30 ISO 4017/Galvanized
26
Hexagon self- locking nut M8 ISO 7040
12
Hexagon socket button cup screw M4x12 ISO 7380/Galvanized
4
Flat washer 4,3x9 ISO 7089 Galvanized
20
Hexagon self- locking nut M4 ISO 7040
10
Screw M4x10 UNI UNI 7688-4 Galvanized
6
Grid side
10
Srew TBEI M8 X 20 ISO 7380/Galvanized
10
Flat washer 6,4 x 12 ISO 7089 Galvanized
5
Hexagon screw M6x16 ISO 4017/Galvanized
9
Exagon nut M6 ISO 4032/Galvanized
1
Hexagon screw M6x25 ISO 4017/Galvanized
1
Flat washer 17x30 ISO 7089 Galvanized
3
Hexagon self- locking nut M16 ISO 7040
12
Hexagon self- locking nut M6 ISO 7040
16
Flat washer 10,5 x 21 ISO 7089 Galvanized
8
Hexagon screw M10x30 ISO 4017/Galvanized
2
Hexagon screw M10x25 ISO 4017/Galvanized
2
Hexagon screw M16x50 ISO 4017/Galvanized
4
Hexagon socket button cup screw M10x20 ISO 7380/Galvanized
3
Hexagon socket button cup screw M6x15 ISO 7380/Galvanized
4
Cage nut M6
4
Socket head flat countersunk M6x20 ISO 10642/Galvanized
4
Exagon nut M10 ISO 4032/Galvanized
4
Hexagon socket button cup screw M8x30 ISO 7380/Galvanized
10
Flat washer large series 6,4 x 18 ISO 7093 Galvanized
4
Hexagon socket button cup screw M6x20 ISO 7380/Galvanized
2
Exagon nut M8 ISO 4032/Galvanized
2
Flat washer 5,3x100 ISO 7089 Galvanized
2
Spacer
2
Hexagon screw M5x10 ISO 4017 Galvanized
4
Socket head flat countersunk M6x25 ISO 10642/Galvanized
2
Central grid
1
Handle
1
Claxon 12 V
1
Pedipulator
1
Closure
1
Flat washer 6,4x24 UNI 6593 Galvanized
1
Hexagon screw M6x40 ISO 4017/Galvanized
1
Cap for handle
1
Hexagon screw M6x20 ISO 4017/Galvanized
6
Plate for self-tapping screw 4,8
6
Self-tapping screw 4,8 Black
2
Plate of attack
Description
