10
85
3009150 TUBO DA POLMONE A VAPORIZZATORE
10
86
3009149 TUBO DA MOTORE A POLMONE
10
87
3009153 TUBO DA POLMONE A MOTORE
10
88
3009152 TUBO DA POMPA ACQUA A POLMONE
10
89
4200857 TUBO ALIMENTAZIONE GAS
10
90
3008452 TUBO PER SFIATO BATTERIA L.350
10
91
3008453 TUBO PER SFIATO BATTERIA L.700
10
92
3008931 TUBO MANDATA ACQUA
10
93
3008932 TUBO RITORNO ACQUA
10
94
3008928 CAMPANA KUBOTA SAE B FRESATA
10
95
4201916 GIUNTO KUBOTA SAE B Z13
10
96
4200794 SCAMBIATORE
10
97
4200795 TEMPORIZZATORE 60/50°
10
98
4201749 VASCHETTA RECUPERO ACQUA
10
99
4201750 TAPPO VASCHETTA
10
100
4300036 RONDELLA D.8,4 X 17 UNI 6592 ZINC.
10
101
4300053 DADO M8 AUTOFRENANTE UNI 7473
10
102
4300127 VITE TE M8X60 1/2 FILETTO UNI 5739 ZINC.
10
103
4300034 RONDELLA D.10,5X 21 UNI 6592 ZINC.
10
104
4300328 VITE TCEI M10X35 UNI 5931-8.8 ZINC.
10
105
4300126 RONDELLA D.8X24 UNI 6592 ZINC.
10
106
4300048 RONDELLA D.6,4 X 12 UNI 6592 ZINC.
10
107
4300050 VITE TE M6X20 UNI 5739 ZINC.
10
108
4300247 VITE TBEI M6 X15 ISO 7380 ZINC.
10
109
4300224 RONDELLA D. 6,4 X 18 UNI 6593 ZINC.
10
110
4300173 VITE TBEI 6X20 ISO 7380 ZINC.
10
111
4300051 DADO M6 AUTOFRENANTE UNI 7473 ZINC.
10
112
4300232 VITE TBEI M8 X 30 UNI-ISO 7380
10
113
4300222 VITE TBEI M8 X 20 ISO 7380 ZINC.
10
114
4300087 VITE TE M6X25 UNI5739 ZINC.
10
115
4300492 RONDELLA DENTELLATA D8,4X15 DIN 6798 A
10
116
4300246 Vite TCEI M8 x 16 UNI 5931-8.8 ZINC.
10
117
4300208 VITE TE M6 X 60 UNI 5739-8.8 ZINCATA
10
118
4300061 VITE TE M8 X 70 UNI 5739-8.8 ZINCATA
10
119
4300079 DADO MEDIO M6 UNI 5588-6S ZINC.
10
120
4300351 VITE TSPEI M6 X 25 UNI 5933 ZINC.
10
121
4300437 VITE TSPEI M6 X 20 UNI 5933 ZINC.
10
122
4300049 RONDELLA 4.3 X 9 UNI6592
10
123
4300056 DADO M4 AUTOFRENANTE UNI 7473 ZINC.
10
124
4300158 VITE TBEI M4 X 12 UNI7380
10
125
4300293 VITE TE M8 X 25 UNI 5739-8.8 ZINCATA
10
126
4300431 VITE TSPEI M8 x 25 UNI 5933 ZINC.
10
127
4300352 VITE TE M6 X 12 UNI 5739-8.8 ZINCATA
10
128
4300148 VITE TBEI M6 X 10 UNI-ISO 7380
10
129
4300116 VITE TSPEI M6 X 16 UNI 5933-8.8 ZINC.
10
130
4300107 VITE TE M8 X 15 UNI 5739-8.8 ZINCATA
10
131
4300114 RONDELLA GROOVER D.8 UNI 1762
10
132
4300029 DADO MEDIO M8 UNI 5588-6S ZINC.
10
133
4300455 VITE TE M14 X 30 UNI 5739 ZINC.
10
134
4300463 VITE TCEI M10X25 UNI 5931 ZINC.
10
135
4300070 DADO M10 AUTOFRENANTE UNI 7476
10
136
4300204 VITE TE M10 X 30 UNI 5739 - 8.8 ZINC.
10
137
4300479 VITE TSPEI M8 X 35 UNI 5933 ZINC.
10
138
4300256 RONDELLA GROOVER D.10 ZINC:
10
139
4300108 VITE TE M8 X 30 UNI 5739-8.8
10
140
4300213 VITE TE M8 X 50 UNI 5739 ZINC.
10
141
4300255 VITE TCEI M8X50 1/2 FIL. UNI 5931 ZINC.
10
142
4300192 RONDELLA GROOVER D.6 UNI 1762
10
143
4300174 VITE TCEI M6X20 UNI 5931 ZINC.
10
144
4201987 VENTOLA
10
145
4201901 CINGHIA AVX10 X 925LA
10
146
4201228 SPINA CILINDRICA H6 8 X 20
Part Nr refers always to one single parts
GRUPPO MOTORIZZAZIONE 2210368
1
Pipe from lung to vaporizer
1
Pipe from engine to lung
1
Pipe from engine to lung
1
Pipe from water lung to lung
1
Pipe Gas supply
1
Breather tube L.350
1
Breather tube L.700
1
Water return pipe
1
Water delivery pipe
1
Coupling Kubota SAE B
1
Joint for coupoling SAE B Z13
1
Heat exchanger SCM.A26 12V
1
Oli thermometer 60/50 °C
1
Recovery tank
1
Tank cap
42
Flat washer large series D.8x17 ISO 7093 Galvanized
24
Hexagon self- locking nut M8 ISO 7040
1
Hexagon screw partially treaded M8x60 ISO 4014 Galvanized
24
Flat washer large series D.10,5x 21 ISO 7093 Galvanized
2
Socket head cup screw M10x35 ISO4762 Galvanized
13
Flat washer large series D.8x24 ISO 7093 Galvanized
36
Flat washer large series D.6,4x 12 ISO 7093 Galvanized
14
Hexagon screw M6x20 ISO 4017/Galvanized
19
Hexagon socket button cup screw M6x15 ISO 7380/Galvanized
30
Flat washer large series D.6,4x18 ISO 7093 Galvanized
5
Hexagon socket button cup screw M6x20 ISO 7380/Galvanized
18
Hexagon self- locking nut M6 ISO 7040
2
Hexagon socket button cup screw M8x30 ISO 7380/Galvanized
4
Hexagon socket button cup screw M8x20 ISO 7380/Galvanized
1
Hexagon screw M6x25 ISO 4017/Galvanized
2
Washer D 8,4x15 DIN 6798 A
2
Socket head cup screw M8x16 ISO4762 Galvanized
2
Hexagon screw M6x60 ISO 4017/Galvanized
4
Hexagon screw M8x70 ISO 4017/Galvanized
1
Exagon nut M6 ISO 4032/Galvanized
1
Socket head flat countersunk M6x25 ISO 10642/Galvanized
1
Socket head flat countersunk M6x20 ISO 10642/Galvanized
2
Flat washer large series D.4,3 x 9 ISO 7093 Galvanized
2
Hexagon self- locking nut M4 ISO 7040
2
Hexagon socket button cup screw M4x12 ISO 7380/Galvanized
6
Hexagon screw M8x25 ISO 4017/Galvanized
1
Socket head flat countersunk M8x 25 ISO 10642/Galvanized
6
Hexagon screw M6x12 ISO 4017/Galvanized
12
Hexagon socket button cup screw M6x10 ISO 7380/Galvanized
5
Socket head flat countersunk M6x 16 ISO 10642/Galvanized
2
Hexagon screw M8x15 ISO 4017/Galvanized
10
Split washer D.8 DIN 127/ Galvanized
4
Exagon nut M8 ISO 4032/Galvanized
2
Hexagon screw M14x30 ISO 4017/Galvanized
2
Socket head cup screw M10x25 ISO4762 Galvanized
12
Hexagon self- locking nut M10 ISO 7040
4
Hexagon screw M10x30 ISO 4017/Galvanized
5
Socket head flat countersunk M8x35 ISO 10642/Galvanized
8
Split washer D.10 DIN 127/ Galvanized
4
Hexagon screw M8x30 ISO 4017/Galvanized
2
Hexagon screw M8x50 ISO 4017/Galvanized
2
Socket head cup screw M8x50 ISO4762 Galvanized
2
Split washer D.6 DIN 127/ Galvanized
2
Socket head cup screw M6x20 ISO4762 Galvanized
1
Fun
1
Belt AVX10x925LA
1
Cylindrical pin H6 8 X 20
