KIT SPAZZOLA LATERALE SX 2110525
TAB.
POS.
COD.
14
1
2101629
Supporto spazzola sinistro
14
2
2101512
Braccio spazzola laterale sinistro
14
3
4200622
Bussola K4 20x23x20
14
4
2110528
Braccio spazzola sinistro
14
5
4300036
Rondella D.8,4 X 17 UNI 6592 ZINC.
14
6
4300033
Vite TE M8 X 20 UNI 5739-8.8 ZINC.
14
7
3000098
Rondella per albero di comando
14
8
4300178
Dado Esag.medio M10 UNI 5588 ZINC.
14
9
4300227
Vite TE M10 X 40 UNI 5739-8.8 ZINC.
14
10
4300029
Dado Medio M8 UNI 5588-6S ZINC.
14
11
4300108
Vite TE M8 X 30 UNI 5739-8.8 ZINC.
14
12
4300126
Rondella D.8 X 24 UNI 6592 ZINC
14
13
4300061
Vite TE M8 x 70 UNI 5739 8.8
14
14
4200693
Molla rientro spazzola
14
15
3001511
Rondella di fermo molla
14
16
4300053
Dado M8 Autofrenante UNI 7473 6S ZINC.
14
17
4300058
Rondella D.13X 24 UNI 6592 ZINC.
14
18
4300006
Vite TE M10x85 1/2 filetto UNI 5737 Zinc.
14
19
4300070
Dado M10 Autofrenante UNI 7473-6S ZINC.
14
20
4211580
Motore idraulico BMP 125
14
21
2101938
Mozzo spazzola laterale
14
22
3007959
Spazzola laterale
14
23
4300289
Vite TSPEI M8 X 40 UNI 5933 zinc.
14
24
3001583
Supporto SX per martinetto spazzola
14
25
3010060
Da motore spazzola a raccoglitore
14
26
4300226
Vite TCEI M12 X 35 UNI 5931-8 8 ZINC.
14
27
3010058
Da distributore tre elementi a cilindro spaz. Lat.
14
28
4200922
Linguetta 8X7X32 UNI 6604 / 69
14
29
3002675
Tubo idraulico da motore a motore
14
30
3002676
Tubo idraulico da cilindro a cilindro
14
31
3002677
Tubo idraulico da cilindro a cilindro
14
32
4200491
Rondella Bonded seal 1/4"
14
33
4200711
Occhio filettato con battuta 1/4"
14
34
4200636
Valvola di blocco 1/4" 0,5 / BAR
14
35
4200699
Bullone forato per occhio 1/4"
14
36
4200490
Rondella Bonded seal 1/2"
14
37
4200704
Bussola bassa di riduzione 1/2"M - 3/8" F
14
38
4200473
Rondella Bonded seal 3/8"
14
39
4200767
Bocchettone doppio da 1/4"
14
40
4200745
Adattatore a "T" M - M - F - GIREVOLE 3/8"
14
41
4200707
Riduzione 1/4" M - 3/8" F (BSP 60°)
14
42
4200709
Prolunga M-F 3/8" L=40 (BSP 60°)
14
43
4200700
Bullone forato per occhio 3/8"
14
44
3002233
Cilindro spazzola
14
45
3010059
Da cilindro spazzola laterale a motore spazz.
Part Nr
refers always to one single parts
DENOMINAZIONE
QTy
1
Left side broom support
1
Left side broom arm
2
Socket K4 10 x 12 x 10
1
Left broom arm
10 Flat washer D 8,4x17 ISO 7089 Galvanized
10 Hexagon screw M8x20 ISO 4017/Galvanized
2
Washer for drive shaft
2
Exagon nut M10 ISO 4032/Galvanized
2
Hexagon screw M10x40 ISO 4017/Galvanized
1
Hexagon nut M8 ISO 4032 Galvanized
1
Hexagon screw M8x30 ISO 4017/Galvanized
1
Flat washer large series D.8x24 ISO 7093 Galvanized
1
Hexagon screw M8x70 ISO 4017/Galvanized
1
Spring
1
Spring stop washer
4
Hexagon self- locking nut M8 ISO 7040
4
Flat washer13 x 24 ISO 7089 Galvanized
1
Hexagon screw M10x85 ISO 4017/Galvanized
1
Hexagon self- locking nut M10 ISO 7040
1
Hydraulic motor BMP 125
1
Side broom hub
1
Side brooom PP
3
Socket head flat countersunk M8x40 ISO10642 Galvanized
1
Support left broom cylinder
1
Hydraulic pipe from hydraulic motor to collector
2
Socket head cup screw M12x35ISO4762 Galvanized
1
Hydraulic pipe from 3 element distributor to main broom cylinder
1
Key 8x7x32 ISO 773A
1
Hydraulic pipe from hydraulic motor to hydraulic motor
1
Hydraulic pipe from cylinder to cylinder
1
Hydraulic pipe from cylinder to cylinder
13 Bonded seal washer 1/4"
2
Treaded grommet 1/4"
1
Stop valve 1/4" 0,5 BAR
4
Pipe union 1/4"
2
Bonded seal washer 1/2"
2
Reduction bush 1/2"M -3/8"F
4
Bonded seal washer 3/8"
1
Pipe union 1/4"
1
"T" adaptor M - M - F - revolving 3/8"
1
Reduction 1/4" M - 3/8" F (BSP 60°)
1
Extention M-F 3/8" L=40 (BSP 60°)
2
Pipe union 3/8"
1
Broom cylinder
1
Hydraulic pipe from main broom cylinder to broom idraulic motor
Desciption
