TAB.
POS.
Part Nr.
17
1
3003636 Supporto vaschetta tergicristallo
17
2
2103911 Cofano sedile con cabina
17
3
2103924 Cofano sedile fisso
17
4
4300033 Vite TE M8x20 UNI 5739-8.8 Zincata
17
5
4300036 Rondella D.8,4x18 UNI 6592 Zincata
17
6
4300224 Rondella D.6,4x18 UNI 6593 Zincata
17
7
4300247 Vite TBEI M6x15 UNI 7380 Zincata
17
8
4200875 Girofaro 12 Volt Magnetico
17
9
4300469 Grano M8x35 ISO 4027/DIN 914 Zincato
17
10
4300029 Dado medio M8 UNI 5588 Zincato
17
11
4300126 Rondella D.8x24 UNI 6593 Zincata
17
12
4300053 Dado M8 Autofrenante UNI 7473 Zincato
17
13
3000098 Rondella per albero di comando
17
14
4300232 Vite TBEI M8x30 UNI-ISO 7380 Zincata
17
15
4300051 Dado M6 Autofrenante UNI 7473 Zincato
17
16
3009326 Mousse appoggio cofano L.507mm
17
17
3009051 Lamiera per chiusura cofano sedile
17
18
3009052 Profilo mousse 20x40 L.240mm
17
19
4300048 Rondella D.6,4x12 UNI 6592 Zincata
17
20
4300437 Vite TSPEI M6x20 UNI 5933-8.8 Zincata
17
21
3009055 Guarnizione trafilata armata L.410 mm
17
22
4300116 Vite TSPEI M6x16 UNI 5933-8.8 Zincata
17
23
4200859 Serbatoio acqua + pompa
17
24
4300049 Rondella D.4,3x9 UNI 6592 Zincata
17
25
4300158 Vite TBEI M4x12 UNI-ISO 7380 Zincata
17
26
4200860 Valvola di non ritorno
17
27
3009310 Tubo alimentazione acqua
17
28
4300289 Vite TBEI M8x40 UNI-ISO 7380 Zincata
17
29
3009180 Cristallo laterale posteriore destro
17
30
4201977 Bussola in plastica
17
31
3009195 Gomma vetro posteriore
17
32
4201973 Maniglia vetro posteriore
17
33
3009196 Gomma di appoggio destra
17
34
4209334 Tappo per telaio porta
17
35
4201979 Gommino vetro posteriore
17
36
4201839 Cerniera portiera cabina chiusa
17
37
4200431 Vite TSPEI M8x25 UNI 5933-8.8 Zincata
17
38
2108391 Fermo vetro Sinistro
17
39
6252624 Antivibrante D.20 M6
17
40
2108392 Fermo vetro Destro
17
41
3008373 Biella
17
42
3009184 Cristallo inferiore lato Sx
17
43
5.3E+08 Dado esagonale a frenatura centrale M8x6,5 DIN 980
17
44
4300087 Vite TE M6x25 UNI 5739-8.8 Zincata
17
45
3009185 Cristallo anteriore lato Sx
17
46
3009186 Cristallo posteriore lato Sx
17
47
3008375 Piatto attacco biella Dx
17
48
3009189 Gomma lunga lato porta
17
49
3009190 Gomma verticalale lato porta
17
50
3008051 Supporto attacco girofaro
17
51
4201252 Presa femmina per girofaro
17
52
3008374 Piatto attacco biella Sx
17
53
4300439 Vite TBTC M4x25 UNI 6107 Zincata
17
54
3006246 Lamiera chiusura cabina
17
55
3009193 Gomma lato Sx
17
56
3009069 Pannello fonoassorbente
17
57
4201970 Serratura porta
17
58
3008372 Cavallotto
17
59
4300487 Vite TCEI M5x40 UNI 5931 Zincata
17
60
4201975 Cingia sicura porta
17
61
2108995 Traversa vetro posteriore
17
62
4300210 Vite TSPEI M8x20 UNI 5933-8.8 Zincata
17
63
4201972 Cerniera vetro posteriore
17
64
3009187 Cristallo posteriore
17
65
4300045 Rondella D.5,5x15 UNI 6593 Zincata
17
66
4300486 Vite TSPEI M8x30 UNI 5933-8.8 Zincata
17
67
4201971 Luce interna
17
68
3009191 Gomma inferiore lato porta
17
69
3009192 Gomma lato vetro anteriore
17
70
4300041 Dado M6 Autofrenante UNI 7473 Zincato
17
71
4201976 Aletta parasole
17
72
3009194 Gomma posteriore
17
73
4300379 Vite autofilettante 4,8x19 Nera
17
74
4201974 Griglia posteriore
17
75
4200293 Vite TE M8x25 UNI 5739-8.8 Zincata
17
76
3002665 Vetro anteriore
17
77
4201856 Motore tergivetro
17
78
4201857 Asta tergivetro
17
79
4201858 Spazzola tergivetro
17
80
3009181 Cristallo porta
17
81
3009182 Telaio porta vetro
17
82
3009248 Guarnizione inferiore sulla porta
17
83
4300331 Spina elastica D.5x24
17
84
4200724 Lampada 12V-5W
17
85
4201003 Lampada alogena 12V-55W
17
86
4200857 Ugello acqua
17
87
3009325 Mousse appoggio cofano L.700mm
Part Nr refers always to one single parts
Cabina chiusa 2103935
DENOMINAZIONE
Q.ty
1
Support reservoir
1
Seat bonnet with cabin
1
Fixed bonnet
2
Hexagon screw M8x20 ISO 4017/Galvanized
7
Flat washer 8,4 x 18 ISO 7089 Galvanized
10
Flat washer large series D.6,4 x18 ISO 7093 Galvanized
3
Hexagon socket button cup screw M6x15 ISO 7380/Galvanized
1
Rotating flash12V magnetic base
2
Grub screw M8x35 ISO 4027/DIN 914 Galvanized
6
Exagon nut M8 ISO 4032/Galvanized
4
Flat washer large series D.8 x24 ISO 7093 Galvanized
8
Hexagon self- locking nut M8 ISO 7040
1
Washer
5
Hexagon socket button cup screw M8x30 ISO 7380/Galvanized
8
Hexagon self- locking nut M6 ISO 7040
2
Bonnet gasket support L. 507 mm
1
Plate for closing the bonnet seat
2
Gasket 20x40 L.240mm
2
Flat washer 6,4x12 ISO 7089 Galvanized
2
Socket head flat countersunk M6x20 ISO 10642/Galvanized
1
Gasket L.410mm
10
Socket head flat countersunk M6x16 ISO 10642/Galvanized
1
Screen wash water reservoir + pump
8
Flat washer 4,3x9 ISO 7089 Galvanized
3
Hexagon socket button cup screw M4x12 ISO 7380/Galvanized
1
One direction valve
1
Water hose
2
Hexagon socket button cup screw M8x40 ISO 7380/Galvanized
1
Right rear side glass
2
Plastic bush
1
Gasket for rear glass
1
Handle for rear glass
1
Right rubber gasket
8
Cup for frame door
2
Rubber rear window
2
Car door hinge
4
Socket head flat countersunk M8x25 ISO 10642/Galvanized
1
Left lock glass
4
Anti vibration M6
1
Right lock glass
2
Rod
1
Left side lower glass
2
Exagon nut M8 DIN 980/Galvanized
4
Hexagon screw M6x25 ISO 4017/Galvanized
1
Left side front glass
1
Left side rear glass
1
Right coupling rod plate
1
Long rubber side door
1
Rubber vertical side door
1
Rotating flash female socket support
1
Female socket for rotating flash
1
Left coupling rod plate
2
Screw M4x25 ISO 7048 Galvanized
1
Closing plate cab
1
Left side rubber
1
Sound absorption panel
1
Door lock
2
U-shaped support
1
Socket head cup screw M5x40 ISO4762 Galvanized
1
Secure door strap
1
Cross back glass
4
Socket head flat countersunk M8x20 ISO 10642/Galvanized
2
Hinge rear window
1
Rear glass
2
Flat washer large series D.5,5 x15 ISO 7093 Galvanized
2
Socket head flat countersunk M8x30 ISO 10642/Galvanized
1
Internal light
1
Rubber lower side door
1
Rubber side front glass
1
Hexagon self- locking nut M6 ISO 7040
1
Sun visor
1
Rear rubber
2
Self-tapping screw 4.8 black
1
Rear grille
2
Hexagon screw M8x25 ISO 4017/Galvanized
1
Front glass
1
Wiper motor
1
Rod wiper
1
Brush squeegee
1
Door glass
1
Farme door glass
1
Bottom seal on the door
1
Spring pins D.5x24 ISO 8752
1
Lamp 12 V - 5 W
1
Halogen lamp 12 V- 55 W
1
Water nozzle
2
Bonnet gasket support L. 700 mm
Description
