1. According to the current to be measured rotate function selector
switch to either position of uA, mA or 10A.
2. P 3350 only: Set the device to the DC measurement function
(DC " ") by pressing the MODE key. In the LCD display the
operation icon (DC "
3. For current measurements up to 60 µA DC, set the function
switch to the "µA" position and insert the red test lead banana
plug into the mA/µA jack.
4. For current measurements up to 600 mA DC, set the function
switch to the "mA" position and insert the red test lead banana
plug into the mA/µA jack.
5. For current measurements up to 10 A DC, set the function
switch to the 10 A position and insert the red test lead banana
plug into the 10 A jack.
") appears
