GB
Pull the belt taut, so that the lap belt and the diagonal belt fit well,
and ensure that the belts are not twisted. The lap belt should be
in the lowest possible position.
If your vehicle is fitted with a seat belt belt height regulator, adjust
its height accordingly.
When disembarking, all you need to do is open the lock and
pass the belt back across the child. To remove the shoulder belt
from the guide, press down the safety clip (C1) and pull the belt
forward.
It is nevertheless important to ensure that the belts are always
correctly positioned every time they are used.
Figure 2 illustrates the correct method of installation. Incorrect
variations are depicted in Figures 6 and 7. If you have any doubts
about installation, please contact us to check.

4. Special accessories: fastening belts

(Figures 8 to 10)
We have devised fastening belts by way of special accessories for
the CONCORD LIFT EVO backrest. These belts provide assistance
in positioning the child car seat. Any drawbacks that may present
themselves as a result of different designs of car seats can be
compensated for with the help of the fastening belts.
Important: These fastening belts are not an integral part of the
safety system.
Begin by selecting the most appropriate car seat fitted with a
three-point (seat) belt. Make sure that you can pass the fastening
belts round the backrest of the chosen car seat.
The front passenger seat or a folding back bench is ideal.
Our diagrams demonstrate several possible ways of fastening
the belts.
14
