Asskea proVisio Serie Gebrauchsanweisung Seite 75

Symbol Description
Button illuminates continuously green
Button illuminates continuously red
Button illuminates continuously green
Button illuminates continuously red
Button illuminates continuously green
Button illuminates continuously red
Display illuminates continuously green
Display illuminates continuously orange Battery capacity < 60% to 10%
Display illuminates continuously red
Display blinks green
Display blinks red
Display illuminates continuously green Power supply unit is connected, voltage available.
Display blinks red
Button illuminates continuously green
Button illuminates continuously orange Device still runs for 30 seconds before it switches off automatically.
Button illuminates continuously red
Meaning of display
Device is running, `High´ vacuum setting is adjusted (-0.5 bar < vacuum ≤ -0.9 bar)
Canister full / filter blocked (motor switches off automatically)
Device is running, `Medium´ vacuum setting is adjusted (-0.2 bar < vacuum ≤ -0.5 bar)
Canister full / filter blocked (motor switches off automatically)
Device is running, `Low´ vacuum setting is adjusted (vacuum ≤ -0.2 bar)
Canister full / filter blocked (motor switches off automatically)
Battery capacity 100% to 60%
Battery capacity < 10%, connect power supply unit immediately. Switch
off the device after completion of the aspiration procedure for charging!
Battery is being charged.
Overtemperature protection, interruption of charging process until battery
temperature returns to permissible range.
Battery defective, operation only possible with connected power supply unit.
Please contact your service partner!
Incorrect power supply unit is connected, no charging of battery possible!
Device is switched on and ready for use.
Afterwards the button will still be illuminated for 10 seconds.
Internal error, operation is not possible.
Please contact your service partner!
4 Maintenance
