ESAB A2 Multitrac Betriebsanweisung Seite 146

Item
Qty Orderingno.
no.
415 855- - 880
01 2 332 979- -890
02 2 332 976- -880
03 12 2121 107- -42
04 6 2121 081- -02
07 4 415 857- -001
08 4 2111 029- -62
09 2 415 856- -001
10 1 332 990- -880
11 1 0409 536- -02
12 1 192 784- -001
13 2 192 784- -101
14 1 2188 101- -87
15 2 2122 043- -44
16 1 333 093- -880
17 1 321 220- -001
18 1 2121 107- -15
19 4 2121 014- -44
20 4 2151 000- -10
21 1 2182 015- -01
22 1 2182 015- -01
23 2 2182 016- -01
24 3 333 086- -002
25 3 2111 029- -52
26 12 2121 015- -03
27 12 2151 000- -11
29 4 333 087- -007
30 6 192 238- -378
31 1 191 309- -320
32 191 309- -112
33 1 191 309- -105
34 1 332 975- -001
35 6 2121 107- -17
36 4 190 437- -370
37 4 2151 002- -01
38 1 413 514- -880
dha2r11a
Denomination
Carriage
Guide arm
Side plate
Screw
Screw
Wheel
Roll pin
Shaft
Motor gear with clutch
Clamp
Pin plug
Pin
Handwheel
Stop screw
Motor cable
Cable bushing
Screw
Screw
Washer
Chain
Chain
Chain lock
Sprocket
Roll pin
Screw
Washer
Y- -flange support
Screw
Clamp
Clamp
Clamp
Cover plate, base
Screw
Screw
Washer
Cover
- - 146 - -
Notes
B12x16
M6x8
M12
M5x12
B6x25
M4x12
D16/8.4x0.8
L = 400
L = 705
D6x50
M5x12
D10x5.3x1
M6x30
D20
D25
D12
B8x9.5
M6x20
D22/6.4x4
C
