Power Switch Function

The two position power switch on the Modbar module back panel has two separate functions: ON and
OFF.
0 Off
In this position, the module is in the off position.
I Standby Mode
In this position, the module is in standby mode. When in
standby mode, all operations function as normal, but no
power is applied to the heating elements. This mode is used
for priming the system upon installation, and can also be
useful for some diagnostic applications.
II Operating Mode
In this position, the module is in operating mode. Power is
applied to the heating elements, and all functions operate as
normal.

Startup Instructions

Installation

Minimum room temperature: 5°C/41°F.
Maximum room temperature: 32°C/89°F.
The weighted sound pressure level of the machine is lower than 70dBA.
In order to connect the machine up to the water mains proceed according to the indications given in the
Installation Guide and in compliance with any local/national safety standards of the location in which
the machine is being installed.
In order to prevent cracks or leakage: do not store or install the coffee machine in places where
temperature may cause water in boiler or hydraulics system to freeze.
Upon installation, the Modbar module must be primed before use. This is accomplished by the following
steps.
Ensure that filtered water is supplied to the module.
Ensure that the power switch is in the off position.
Ensure that the module power cable is plugged into its appropriate power source.
Turn the power switch counter clockwise to place it in standby mode.
Actuate the tap handle in manual mode, as described in the "Dispensing Operations" section of
this guide.
After water begins to pour from the tap (This may take some time on a new system) allow water
to flow for at least 30 seconds to ensure that the system is primed.
At this point, it is safe to turn the switch clockwise into operating mode.
P O S
OUR VER YSTEM
Power Switch
OFF position
