6.5 Modem / PC Link

It is necessary to configure the modem in the "Modem" menu.
Refer to the installation instructions of the remote diagnosis
system used regarding installation regulations. Check all
E-22
Downloaded from www.Manualslib.com
Adjusting the interface for remote diagnostics
Selects the baud rate with which data is exchanged
via the serial interface. Ensure that the same baud
rate is set on both sides of the communication
system.
An address can be assigned to each connection.
This value should remain set to 001 in normal
operation.
Setting the protocol specifies which type of remote
diagnostics are used (local or modem)
The remote diagnostic function can be locked by a
password
This function is currently not in use
This sets which type of telephone connection is
used for remote diagnostics via modem
This sets the number of rings after which the
controller for remote diagnostics answers
This function is currently not in use
manuals search engine
changes to the factory settings very carefully because an existing
connection could be severed.
Setting range
19,200
9,600
4,800
2,400
1,200
...001...
Local
Remote
GSM
... 1234...
9,999
Tone
Pulse
... 1...
Display
At all times
0 At all times
199
At all times
0 At all times
At all times
At all times
0 At all times
9
No At all times
Yes
