Configuring the Heat Pump Heating System
Downloaded from www.Manualslib.com
Activation of special functions
Sets the duration of the individual steps during the
heating-down phase
Sets the temperature difference between the two
steps in the heating-up phase
Sets the temperature difference between the two
steps in the heating-down phase
Activates the individual program for screed drying
By activating this function, the difference between
flow and return flow is measured at the start of
defrosting. If the value is > 12 K, a fault is activated.
By activating this function, a fault is activated if an
expected reduction in the flow temperature does
not take place
After-sales service functions
Displays the time to the next defrosting
Setting for selecting the type of external sensor in
use.
After this function is activated, all of the display
segments will be activated for approx. 10 seconds.
Displays all the temperatures measured in the
heating system in compact form
Displays the statuses of all digital outputs in the
heating system in compact form
Displays the statuses of all digital inputs in the
heating system in compact form
Displays all the analogue values measured in the
cooling system in compact form
Displays all the digital inputs and outputs in the
cooling system in compact form
manuals search engine
6.1
Display
1 At all times
... 24...
120
1 K At all times
... 5 K ...
10 K
1 K At all times
... 5 K ...
10 K
No At all times
Yes
No Air HP
Yes
No Air HP
Yes
At all times
At all times
NTC acc. to Controller without
DIN 44574 integrated display
NTC acc. to
DIN Carel
No At all times
Yes
At all times
At all times
At all times
Cooling function
Cooling function
E-21
