Remaining hazards

The machine has been built using modem technology in
accordance with recognized safety rules. Some remaining
hazards, however, may still exist.
• The rotating saw blade can cause injuries to fingers and
hands if the work piece is incorrectly fed.
• Thrown work pieces can lead to injury if the work piece
is not properly secured or fed, such as working without
a limit stop.
• Noise can be a health hazard. The permitted noise level
is exceeded when working. Be sure to wear personal pro-
tective gear such as ear protection.
• Defective saw blades can cause injuries. Regularly in-
spect the structural integrity of saw blades.
• The use of incorrect or damaged mains cables can lead
to injuries caused by electricity.
• The operating instructions supplied with the special
accessories must be observed and carefully read when
scheppach special accessories are used.
• Even when all safety measures are taken, some re-
maining hazards which are not yet evident may still be
present.
• Remaining hazards can be minimized by following the
instructions in „Safety Precautions", „Proper Use" and
in the entire operating manual.

Delivery Package

Scope of delivery
Circular saw bench with motor and switch
Feet and cross-struts
Saw blade Ø 315 mm
Dust bag connector
Covering cap
Suction tube NW 50 x 3 m
Splitting wedge
Longitudinal stop with angle bar
Table extension
Saw blade key
Push stick
Operating instructions
Special accessories – page GB 16
Specifications
Overall length with table extension
Overall length without table extension 750 mm
Overall width
Overall height
Table size
Table height
Saw blade diameter max.
Saw blade diameter min.
Cutting height at 90°
Cutting height at 45°
Cutting width at 90° angular cut
Saw blade height adjustment
Saw blade slewing range
Speed
Cutting speed
Parallel cuts - max. width
Cross cutting jig
Weight
Drive
Electric motor
Motor brake electr. mech.
Input P1
Output P2
Motor speed
Operating mode
Input P1
Output P2
Motor speed
Operating mode
Noise parameters
The noise emission values determined according to EN
23746 for the sound level and according to EN 31202
(coefficient of correction k3 calculated according to Ap-
pendix A.2 of EN 31204) for the sound level at the work-
place are as follows, based on the working conditions list-
ed in ISO 7904 Appendix A:
Dust emission values
The dust emission values measured according to the
"Principles for the inspection of the dust emission (con-
centration parameters) of wood working devices" of the
Technical Committee Wood are below 2 mg/m
permanently reliable compliance with the TRK limit value
for wood dust valid in the Federal Republic of Germany
can be expected if the machine is connected to a proper
operational aspiration with an air speed of at least 20 m/
s.
1215 mm
590 mm
1095 mm
750 x 590 mm
850 mm
315 mm
300 mm
82 mm
65 mm
260 mm
85 mm
90° – 45°
2760/min.
46 m/sec.
345 mm
0° – 60°
62 kg
230/240 V
50 Hz
2.2 kW
1.5 kW
2760/min.
S6 / 40%
4.2 kW
3.0 kW
2860/min.
S6 / 40%
Sound level in dB
Idle running L = 90,5 dB(A)
WA
Operation L = 101,5 dB(A)
WA
Sound level at the workplace in dB
Idle running L = 78,5 dB(A)
pAeq
Operation L = 89,7 dB(A)
pAeq
A measurement uncertainty allowance K = 4 dB
applies to the mentioned emission values.
400/420 V
50 Hz
3.0 kW
2.2 kW
2800/min
S6 / 40%
3 . Thus, a
