Turn the setscrew to set the cutting depth.
V
ery shArP BlAde
3.3 w
orKing instructions
Machine still runs out when the valve lever
is released! On compressed air failure the
valve lever must be released!
4. Service / Maintenance
4.1 P
reVentiVe mAintenAnce
wear, fracture, cracking, or other signs of damage. With-
out a tool clamped in check no-load speed periodically
and after each maintenance. Even if the machine still op-
erates perfectly, the motor should be removed, cleaned
and the four slides checked for wear by a specialist after
approx. 300 to 400 operating hours.
4.1.1 d /
etAching connecting the suPPly hose
Unscrew the coupling with the exhaust air hose so that it
can be pulled back and off.
30
!
The machine must be
cleaned daily. When clean-
ing, examine all parts for
Press the hose coupling to disengage it. You can now pull
out the air supply hose.
V
ery shArP BlAde
4.1.2 r
egrinding the BlAde
The blade can be reground with a commercially available
grinding machine. There are special adapter plates avail-
able for SUHNER blades.
V
ery shArP BlAde
4.1.3 h
Ardening the BlAde
Exclusively SUHNER steel must be used. This can be pur-
chased from the area representative or directly from the
manufacturer. Apply the steel under a light pressure. The
last pass should be along the inside of the blade. When
cutting does not improve, the blade must be replaced.
Contact the area representative or the manufacturer for
further information.
o
utside edge
Make sure that the steel is held flat and over the blade's
centre line.
!
!
